仰视攻牙机
规格
| 几种型号 |
主要规格参数 |
驱动动力配件 |
| 输出轴 |
外形尺寸 |
有效攻牙 |
操控模式 |
输出转速 |
输入电气源 |
|
伺服 |
刹车 |
气缸 |
| STM-008 |
8 |
500×400×1000 |
400×300 |
人机+PLC |
0-3000 |
1P/220V/50HZ |
1KW |
|
|
|
| STM-016 |
16 |
600×400×1000 |
550×350 |
人机+PLC |
0-2500 |
1P/220V/50HZ |
1.5KW |
|
|
|
| STM-032 |
32 |
800×600×1000 |
700×500 |
人机+PLC |
0-2000 |
1P/220V/50HZ |
2KW |
|
|
|
| STM-064 |
64 |
1000×700×1000 |
900×600 |
人机+PLC |
0-2000 |
3P/380V/50HZ |
3.5KW |
|
|
|
| STM-080 |
80 |
1200×900×1000 |
1100×800 |
人机+PLC |
0-2000 |
3P/380V/50HZ |
5KW |
|
|
|
| STM-096 |
96 |
1500×1000×1000 |
1400×900 |
人机+PLC |
0-2000 |
3P/380V/50HZ |
5KW |
|
|
|
| STM-120 |
120 |
1600×1200×1000 |
1500×1100 |
人机+PLC |
0-2000 |
3P/380V/50HZ |
7KW |
|
|
|
| STM-160 |
160 |
1800×1300×1000 |
1700×1200 |
人机+PLC |
0-2000 |
3P/380V/50HZ |
7KW |
|
|
|
| STM-200 |
200 |
2000×1350×1000 |
1900×1250 |
人机+PLC |
0-2000 |
3P/380V/50HZ |
5KW×2 |
|
|
|
| STM-240 |
240 |
2400×1600×1000 |
2300×1500 |
人机+PLC |
0-2000 |
3P/380V/50HZ |
7KW×2 |
|
|
|
| STM-320 |
320 |
2600×1800×1000 |
2300×1700 |
人机+PLC |
0-2000 |
3P/380V/50HZ |
5KW×3 |
|
|
|
| PTM-008 |
8 |
500×400×1000 |
400×300 |
开关+PLC |
0-1200 |
0.5-0.7Mpa |
|
|
特制 |
|
| PTM-016 |
16 |
600×400×1000 |
550×350 |
开关+PLC |
0-1200 |
0.5-0.7Mpa |
|
|
特制 |
|
| BTM-008 |
8 |
500×400×1000 |
400×300 |
人机+PLC |
0-3000 |
3P/380V/50HZ |
|
1.5KW |
|
|
| BTM-016 |
16 |
600×400×1000 |
550×350 |
人机+PLC |
0-2500 |
3P/380V/50HZ |
|
2KW |
|
|
| BTM-032 |
32 |
800×600×1000 |
700×500 |
人机+PLC |
0-2000 |
3P/380V/50HZ |
|
2.5KW |
|
|
Specifications
| Several types |
The main specifications |
Drive power accessories |
| Output shaft |
Physical size |
Effective tapping |
Control mode |
Output speed |
Input electric air |
|
servo |
brake |
cylinder |
| STM-008 |
8 |
500×400×1000 |
400×300 |
man-machine+PLC |
0-3000 |
1P/220V/50HZ |
1KW |
|
|
|
| STM-016 |
16 |
600×400×1000 |
550×350 |
man-machine+PLC |
0-2500 |
1P/220V/50HZ |
1.5KW |
|
|
|
| STM-032 |
32 |
800×600×1000 |
700×500 |
man-machine+PLC |
0-2000 |
1P/220V/50HZ |
2KW |
|
|
|
| STM-064 |
64 |
1000×700×1000 |
900×600 |
man-machine+PLC |
0-2000 |
3P/380V/50HZ |
3.5KW |
|
|
|
| STM-080 |
80 |
1200×900×1000 |
1100×800 |
man-machine+PLC |
0-2000 |
3P/380V/50HZ |
5KW |
|
|
|
| STM-096 |
96 |
1500×1000×1000 |
1400×900 |
man-machine+PLC |
0-2000 |
3P/380V/50HZ |
5KW |
|
|
|
| STM-120 |
120 |
1600×1200×1000 |
1500×1100 |
man-machine+PLC |
0-2000 |
3P/380V/50HZ |
7KW |
|
|
|
| STM-160 |
160 |
1800×1300×1000 |
1700×1200 |
man-machine+PLC |
0-2000 |
3P/380V/50HZ |
7KW |
|
|
|
| STM-200 |
200 |
2000×1350×1000 |
1900×1250 |
man-machine+PLC |
0-2000 |
3P/380V/50HZ |
5KW×2 |
|
|
|
| STM-240 |
240 |
2400×1600×1000 |
2300×1500 |
man-machine+PLC |
0-2000 |
3P/380V/50HZ |
7KW×2 |
|
|
|
| STM-320 |
320 |
2600×1800×1000 |
2300×1700 |
man-machine+PLC |
0-2000 |
3P/380V/50HZ |
5KW×3 |
|
|
|
| PTM-008 |
8 |
500×400×1000 |
400×300 |
switch+PLC |
0-1200 |
0.5-0.7Mpa |
|
|
特制special |
|
| PTM-016 |
16 |
600×400×1000 |
550×350 |
switch+PLC |
0-1200 |
0.5-0.7Mpa |
|
|
special |
|
| BTM-008 |
8 |
500×400×1000 |
400×300 |
man-machine+PLC |
0-3000 |
3P/380V/50HZ |
|
1.5KW |
|
|
| BTM-016 |
16 |
600×400×1000 |
550×350 |
man-machine+PLC |
0-2500 |
3P/380V/50HZ |
|
2KW |
|
|
| BTM-032 |
32 |
800×600×1000 |
700×500 |
man-machine+PLC |
0-2000 |
3P/380V/50HZ |
|
2.5KW |
|
|
