无屑挤压丝攻系列
无屑挤压丝攻与切削丝攻不同之点为攻牙时无排屑排出为其特性,而内螺纹之加工面为压造面外观美丽、光滑、材料铁为连续没切断,螺纹强度约增加30%
精度安定,因无沟心部径大故耐力、扭力强度大,丝攻寿命较长不易折断。适用展延性大之材料。铁板、铜板、铝板、不锈钢板及管类加工。
钢铁用挤压丝攻
非铁合金用挤压丝攻
镀钛处理挤压丝攻
管牙用挤压丝攻
No dust tap series
No dust tap and cutting tap different points for tapping without clearance discharge as its characteristic,
and the internal thread processing surface for pressure made surface appearance beautiful, smooth, material iron
as continuous didn't cut off, thread strength about increased by 30% accuracy stability, because does not have the groove
core diameter die endurance, torsion strength, tap life is long is not easy to break. Applicable ductility of big
material. Iron, copper, aluminum, stainless steel plate and pipe class processing.
Iron and steel with extrusion tap
Nonferrous alloy with extrusion tap
Plating titanium processing extruding tap
Tube teeth with extrusion tap
公 制 | 英 制 | 英 制 | 直 径φ | 四角□ | PT | PS | PF | 直径φ | 四角□ | ||
M3 | W1/8 | 4 | 3.22 | 1/8 | 1/8 | 1/8 | 8 | 6 | |||
M4 | M4.5 | W5/32 | 5 | 4 | 1/4 | 1/4 | 1/4 | 11 | 9 | ||
M5 | M5.5 | W3/16 | 5.5 | 4.5 | 3/8 | 3/8 | 3/8 | 14 | 11 | ||
M6 | U1/4 | W1/4 | 6 | 4.5 | 1/2 | 1/2 | 1/2 | 18 | 14 | ||
U5/16 | W5/16 | 6.1 | 5 | 5/8 | 19 | 15 | |||||
M8 | M7 | 6.2 | 5 | 3/4 | 3/4 | 3/4 | 23 | 17 | |||
M10 | M9 | U3/8 | W3/8 | 7 | 5.5 | 7/8 | 24 | 19 | |||
M11 | U7/16 | W7/16 | 8 | 6 | 1 | 1 | 1 | 26 | 21 | ||
M12 | 8.5 | 6.5 | 11/8 | 11/8 | 28 | 21 | |||||
U1/2 | W1/2 | 9 | 7 | 11/4 | 11/4 | 11/4 | 32 | 26 | |||
M14 | M15 | U9/16 | W9/16 | 10.5 | 8 | 13/8 | 13/8 | 13/8 | 35 | 26 | |
U5/8 | W5/8 | 12 | 9 | 11/2 | 11/2 | 11/2 | 38 | 29 | |||
M16 | 12.5 | 10 | |||||||||
M17 | 13 | 10 | |||||||||
M18 | U3/4 | W3/4 | 14 | 11 | |||||||
M20 | 15 | 12 | |||||||||
M22 | U7/8 | W7/8 | 17 | 13 | |||||||
M24 | M25 | 19 | 15 | ||||||||
M27 | M26 | U1 | W1 | 20 | 15 | ||||||
M28 | 21 | 17 | |||||||||
U1-1/8 | W1-1/8 | 22 | 17 | ||||||||
M30 | 23 | 17 | |||||||||
M32 | U1-1/4 | W1-1/4 | 24 | 19 | |||||||
M33 | 25 | 19 | |||||||||
M35 | M34 | U1-3/8 | W1-3/8 | 26 | 21 | ||||||
M36 | M36 | 28 | 21 | ||||||||
M39 | M40 | U1-1/2 | W1-1/2 | 30 | 23 | ||||||
M42 | W1-5/8 | 32 | 26 | ||||||||
M45 | U1-3/4 | W1-3/4 | 35 | 26 | |||||||
M48 | W1-7/8 | 38 | 29 |
